BOSCH - Rotary Hammer SDS Plus GBH 220
So compact, so powerful – Bosch’s rotary hammer now within reach
- Powerful 720 W motor and 2.0 J of impact energy for effective hammer drilling in concrete (up to 22-mm diameter)
- Three-mode rotary hammer for hammer drilling, drilling, and chiselling – ensuring versatility and convincing results
- Compact rotary hammer offers professional Bosch hammer performance within reach
|
TECHNICAL SPECIFICATIONS OF GBH 220 |
|
|
Rated input power |
720 W |
|
Impact energy |
2 J |
|
Weight |
2.3 kg |
|
Impact rate at rated speed |
0 – 4,800 bpm |
|
Tool dimensions (width) |
88 mm |
|
Tool dimensions (length) |
334 mm |
|
Tool dimensions (height) |
205 mm |
|
Tool holder |
SDS plus |
|
Drilling Range : |
|
|
Drilling dia. concrete, hammer drill bits |
4 – 22 mm |
|
Max. drilling diameter in metal |
13 mm |
|
Max. drilling diameter in wood |
30 mm |
|
Max. drilling diameter concrete |
22 mm |
|
Total Vibration Values (Hammer Drilling in concrete) |
|
|
Vibration emission value ah |
14.7 m/s² |
|
Uncertainty K |
1.5 m/s² |
|
Total Vibration Values (Chiselling) |
|
|
Vibration emission value ah |
11.9 m/s² |
|
Uncertainty K |
1.5 m/s² |
|
Hammer Drilling in concrete : |
|
|
Vibration emission value ah |
14.7 m/s² |
|
Uncertainty K |
1.5 m/s² |
|
Chiselling : |
|
|
Vibration emission value ah |
11.9 m/s² |
|
Uncertainty K |
1.5 m/s² |
